Hydraulic Toe Jacks LD1016

These hydraulic jacks have an internal relief valve used to lift and lower heavy loads
to prevent overloading in confined work spaces. Suitable for use in heavy duty
environments with its single mechanism operating both the pump and the release
valve.
• Machine flat front and bottom surfaces permit flush alignment in tight corners
• Pumping handle included

Code LD1015 LD1016 LD1000 LD1001 LD1002 LD1003 LD1004 LD1005 LD1006 LD1007
Hydraulic Hydraulic Hydraulic Hydraulic Hydraulic Hydraulic Hydraulic Hydraulic Hydraulic Hydraulic
Steel Toe Steel Toe Jack 6.5 Jack 20 Jack 20 Jack 30 Jack 30 Jack 60 Jack 60 Jack 100
Description
Jack 5 tonne Jack 10 tonne x tonne x tonne x tonne x tonne x tonne x tonne x tonne x
(360’) tonne (360’) 131mm 275mm 464mm 281mm 470mm 325mm 469mm 310mm
Closed 368mm 420mm 131mm 275mm 464mm 281mm 470mm 325mm 469mm 310mm
Height
Stroke 200mm 230mm 76mm 152mm 305mm 152mm 305mm 152mm 305mm 152mm
Ratchet Jacks
LD1100 LD0105
Capable of lifting five
tonnes on either head or
toe. Ideally suited for work
in difficult conditions.
Used by cranking with
folding handle.
• Low maintenance
• Long life construction
Hydraulic Bottle Jacks • Supports the load

A steel and cast-iron construction with an easy to use indefinitely
hydraulic jack. Used in many different industries for a • Can be used for vertical
variety of lifting jobs. The one-piece base, cylinder and or horizontal operations
reservoir eliminate any potential leaks. Can be used in
horizontal position with the pumping unit located below
the cylinder.
• Supplied with handle, operating lever and sturdy box
• Fitted with a stroke limiting device and safety valves
Code LD1100 LD1101 LD1102
Description Bottle Jack 5 tonne Bottle Jack 10 tonne Bottle Jack 20 tonne Code LD0105
Closed Height 200mm 241mm 270mm Description Ratchet Jack
Stroke 121mm 149mm 159mm Lifting Capacity 5 tonne
