39 / Manual & Powered Lifting

Portable Aluminium Gantries

Lightweight and portable with easy onsite assembly. LD8001
Made up of legs, trolleys and beam components.
Able to extend the height of the legs and a variety
of configurations are available.
• Simple span adjustment and comes on castor
wheels which are 360° locking
• Beam trolley supplied with unit and / or extra
trolley available on request
• Manual handling compliant (EN795 Certified for
Personnel)

Description
1 tonne
2 tonne
2 tonne tall
3 tonne
3 tonne tall
5 tonne
5 tonne tall

Aluminium Gantry Beams
Beam Length
3m 4m 4.5m 5.5m 6m 7m 8.4m
Aluminium Gantry Trolleys

Code LD8020 LD8021 LD8022 LD8023
SWL 1000kg 2000kg 3000kg 5000kg
Aluminium Gantry Legs

Code LD8000 LD8001 LD8002 LD8003 LD8108 LD8004 LD8005
Capacity 1000kg (medium) 2000kg (medium) 2000kg (tall) 3000kg (intermediate) 3000kg (tall) 5000kg (intermediate) 5000kg (tall)
Min Height 2188mm 2188mm 2879mm 2188mm 2879mm 2155mm 2865mm
Max Height 3188mm 3188mm 4079mm 3188mm 4079mm 3155mm 4065mm
Increments 200mm 200mm 200mm 200mm 200mm 200mm 200mm

TC GANTRY NOW AVAILABLE

PORTA Gantry TC range offers all the tested benefits of the standard system but with additional heights of up to 6m.
