324 / Diamond Blades & Consumables Diamond Blades & Consumables / 329

Diamond Blades - For Universal Concrete & Building Materials

DUU/C-SDT Diamond Blade DPU/C Diamond Blade DU/C Diamond Blade

Segment Height: 13MM SDT Segment Height: 13MM Segment Height: 12MM
Dry/Wet: BOTH Dry/Wet: BOTH Dry/Wet: BOTH
Segment Type: SPACE DIAMOND Segment Type: 30 GULLET – Segment Type: SEGMENTED KEY HOLE
o
MICRO SEGMENTS CONICAL SEGMENTED GULLET
Ventilation: YES Ventilation: YES Ventilation: NO
Core Protection: YES – DOUBLE Core Protection: YES Core Protection: NO

FOR CUTTING UNIVERSAL CONCRETE & FOR CUTTING UNIVERSAL CONCRETE & FOR CUTTING UNIVERSAL CONCRETE &
BUILDING MATERIALS BUILDING MATERIALS BUILDING MATERIALS
Laser welded blade with spaced diamond, Laser welded blade with a 30-degree gullet A dry cutting blade with key hole gullet design
micro segments for increased speed and and conical segment design to clear debris for less chipping and reduced vibration. Good
consistent, efficient cutting. Market leading faster and improve life. speed of cut and life.
product life.
APPLICATIONS: APPLICATIONS:
APPLICATIONS: • Indian stone, Granite, Clay products • Hard bricks, Facing bricks
• Indian stone, granite, clay products • Class A Engineering bricks • Lightly reinforced concrete
• Class A Engineering bricks • All reinforced concrete types • Concrete kerbs / Beams / Lintels & Flags
• All reinforced concrete types • Bricks, concrete kerbs, beams, lintels & flags • General purpose
• Occasional asphalt use
• Bricks, concrete kerbs, beams, lintels & • Small metal sections
flags
• Occasional asphalt use Code Diameter (mm) Bore (mm) Code Diameter (mm) Bore (mm)
• Small metal sections
115DPU/C 115 22.20 100DU/C 100 16.00
125DPU/C 125 22.20 115DU/C 115 22.20
Code Diameter (mm) Bore (mm) 230DPU/C 230 22.20 125DU/C 125 22.20
300DPU/C 300 20.00 180DU/C 180 22.20
300DUU/C-SDT 300 20.00
350DUU/C- 350 20.00 350DPU/C 350 20.00 230DU/C 230 22.20
SDT-20 350DPU/C 350 25.40 300DU/C 300 20.00
350DUU/C-SDT 350 25.40 400DPU/C 400 20.00 350DU/C 350 25.40
450DPU/C 450 25.40 350DU/C 350 20.00
500DPU/C 500 25.40
