Page 28 - GAP Green Action Plan

23 / Drilling & Direct Fixing

ET023 ET022

SDS MAX Combi Hammers

Application: heavy-duty drilling and breaking
Materials: reinforced concrete | masonry | stone
Larger than SDS+ systems, SDS MAX combi hammers offer the ultimate in combined drilling and breaking power and
performance. A hybrid machine designed for sustained heavy duty applications that include a mix of breaking, drilling
and hammer drilling. Products come with vibration reduction technology (AVR) that dampen vibrations received by the
operator, allowing for sustained use.
SDS MAX COMBI HAMMERS (6KG - I0KG)
Code ET021 ET093 ET022 ET023
Description 6kg Combi Hammer Combi Hammer TE60 8kg Combi Hammer 10kg Combi Hammer
Model Hilti TE 50-ATC Makita HR4013C Hilti TE 60-ATC-AVR Hilti TE 70-ATC Hilti TE 80-ATC-AVR
Power 1100W 1000W 1350W 1800W 1800W
Impact Energy 6J 8J 7.8J 11.5J 11.5J
HAV Rating (Hammer Drilling Concrete)
9 m/s² 5 m/s² 6.4 m/s² 10 m/s² 7.5 m/s²
Sound Levels -- / 91 dB(A) -- / -- dB(A) -- / -- dB(A) -- / -- dB(A) -- / -- dB(A)
Weight 6.1kg 6.8kg 7.8kg 8.3kg 9.7kg
