Conveyors & Hoists / 22

Niko Scaffold Beams LD4002

The “Niko” scaffolding runway system is an economic and flexible solution in
conveyor systems for loads from 500kg to 1600kg.

This conveyor system is zinc plated for both indoor and outdoor applications.
The Scaffold Runway System connects directly to scaffolding poles to help
move heavy loads around a scaffolding structure.
Beams
Code LD4000 LD4001 LD4002 LD4003 LD4008 LD4004 LD4005
Description Niko Runway Beam Niko Runway Beam Niko Runway Beam Niko Runway Beam Niko Runway Beam Niko Runway Beam Niko Runway Beam
Length (m) 1 2 3 6 2 3 6
SWL (kg) 500 500 500 500 1,000 1,000 1,000
Trolleys
Code LD4010 LD4011
Description Niko Runway Beam Trolley - 500kg Niko Runway Beam Trolley - 1 tonne
SWL (kg) 500 1,000

Supports & Accessories
Code LD4015 LD4016 LD4017 LD4018
Description Niko Runway Scaffold Support Niko Runway Beam Support Niko Runway Beam End Stop Niko Runway Beam Bolt/Nut
Runway Beam

Temporary runway beams for fixing to scaffold systems with a 2t SWL. LD4013
Beams come in 3m lengths and can be joined together for larger lengths.
Bespoke beams can be designed for purchase if you require different
lengths, safe working loads or beams to be fixed to structural steel work
and concrete ceilings.

Code LD4013
Description 2T Runway Beam
SWL (kg) 2000
Length per beam 3m
