9 / Access & Safety

Portable Counterbalance Davit System LD1733

With a safe working load of 120kg-205kg, the Portable
Counterbalance Davit System is ideal for work where access to a
modular system is not available. As well as portable, it is flexible
and modular which makes it suitable for use in a wide range of REMINDER: Do you
applications and environments. need a fall arrest block?
• Composed of a central base unit to accommodate a variety of
anchorage options
• Independent adjustable legs for uneven ground
• 5-piece modular system allowing manual installation
• Suitable for confined spaces
• Trench Box/Sheet Davits can be added to this system

LD1797

Code LD1733 LD1827 LD1828 LD1797
Davit Counterbalance Davit Counterbalance
Description Counterbalance Davit System Weight 15kg Weight 25kg Trench Sheet Davit (Up to 5”) Trench Box Davit (2 ¼” - 25”)
Safety Tripod & Winch

The safety tripod and winch are a temporary option for gaining access to confined LD0740
spaces such as wells, sewage systems etc. The tripod is made from aluminium
and its feet are swivel-mounted and equipped with anti-slip pads. The winch
provides extra safety when lifting or pulling a load.
• Can be used by one or two people weighing up to 150kg each
• Combined weight of tripod and winch is 25kg
• VED system ideal for multi-entry locations
• Suitable for materials lifting up to 500kg
• Complies with EN795B and machinery standards 98/37/CE

Code LD0735 LD0737 LD0740 LD0741 LD0773 SF002
Descender Rescue Aluminium Recovery Man-Riding
Description Rescue Tripod
Block Harness Tripod Winch – 18m Winch
