Diamond Blades & Consumables / 337

Core Drills - Wet Cutting Core Drills - Dry Cutting
DPWC Diamond Core Drill
DUSDC Diamond Core Drill
Segment Height: 8 / 10MM
Dry/Wet: WET Segment Height: 10MM
Segment Type: 8MM CROWN UP TO 32MM THEN 10MM TURBO SEGMENTED Dry/Wet: DRY
Ventilation: WATER COOLED Segment Type: TURBO SHARK SEGMENTS
Barrel Slots: YES
A range of professional, wet diamond cores for high speed and long useful lifetimes. Sizes up to Spiral Flutes: YES
52mm are 1/2" BSP (M) thread. Above 52mm are 1-1/4" UNC (F) thread. FOR DRY CORE DRILLING
APPLICATIONS: A laser welded, shark segmented, conical
Good life and stock removal in concrete and medium hard stone. bodied core drill for ultimate performance and
Reinforced and non-reinforced concrete, plus hard brink and block. life. Free cutting and no snagging.

Code Diameter (mm) Length (mm) Code Diameter (mm) Length (mm) DUSDC Features:
10DPWC 10 150 142DPWC 142 450 The DURO ULTRA Shark core drill features one
12DPWC 12 150 152DPWC 152 450 segment that is narrower than the others and
14DPWC 14 150 162DPWC 162 450 a conical body that is 1mm narrower at its base
16DPWC 16 300 172DPWC 172 450 than at its cutting edge. The benefit of these
features is side clearance – reducing trapping /
18DPWC 18 300 182DPWC 182 450 snagging, vibration and core stress while giving
20DPWC 20 300 202DPWC 202 450 smoother, efficient drilling. No segment loss.
22DPWC 22 300 212DPWC 212 450
24DPWC 24 300 225DPWC 225 450 APPLICATIONS:
25DPWC 25 300 250DPWC 250 450 • Hard York stone
28DPWC 28 300 300DPWC 300 450 • London brick and general house brick
30DPWC 30 300 350DPWC 350 450 • Flint aggregate common
32DPWC 32 300 400DPWC 400 450 • Handmade and facing bricks
35DPWC 35 300 450DPWC 450 450 • Facing bricks
38DPWC 38 400 500DPWC 500 450 • Lightweight concrete block
40DPWC 40 400 • Breeze Block
42DPWC 42 400 • Class A & B engineering bricks
• Concrete
47DPWC 47 400 • Lightly reinforced concrete
52DPWC 52 400
52DPWC 52 400
62DPWC 62 450 Code Diameter (mm) Length (mm)
67DPWC 67 450 38DUSDC 38 150
77DPWC 77 450 52DUSDC 52 150
82DPWC 82 450 65DUSDC 65 150
92DPWC 92 450 78DUSDC 78 150
102DPWC 102 450 92DUSDC 92 150
107DPWC 107 450 102DUSDC 102 150
112DPWC 112 450 107DUSDC 107 150
122DPWC 122 450 117DUSDC 117 150
127DPWC 127 450 127DUSDC 127 150
132DPWC 132 450 152DUSDC 152 150
