Excavators / 137

Excavator Buckets

Using the correct excavator bucket for the correct
excavator is important to ensure on-site productivity.
GAP offer both bucket types, digging and ditching
models in sizes made for all excavators in the GAP
fleet.
• Excavator hires include three buckets as standard

Code BUC06 BUC09 BUC12 BUC18 BUC24 BUC30 BUC48 BUCD1
Bucket Digging Ditching
Size 152mm (6”) 228mm 304mm 457mm 610mm 914mm 1219mm 762mm 914mm 1219mm 1524mm 1829mm
(9”) (12”) (18”) (24”) (36”) (48”) (30”) (36”) (48”) (60”) (72”)
Weight (kg) / Capacity (litres) Weight (kg) / Capacity (litres)
1t Range 16 / 14 22 / 19 40 / 34
1.5t Range 32 / 10 36 / 20 42 / 30 49.4 / 59
3t Range 57 / 50 68 / 80 82 / 139
5/6t Range 76 / 51 95 / 88 167 / 250
8t Range 154 / 143 180 / 210 233 / 350 194 / 290
13t Range 330 / 230 391 / 310 490 / 530 589 / 750 398 / 499
Machine Mounted Laser Code SY0087
SY0087 Detectors Description Machine Mounted Laser Detector

Leica MC200
Used in conjunction with construction Model Topcon LSB-10 Depthmaster
lasers, machine mounted laser detectors Range 700m 200m
allow for excavation depth control when Detection Angle 270° 200°
operating compact excavators and
backhoes all from the comfort of the cab. Attached to the boom, the detector will alarm
and illuminate, notifying the operator when they have reached an optimal digging depth.
These are essential when excavating in areas with buried service cables.
